F15CEHP (2010)
オイルポンプ
Diagram: オイルポンプ
Parts List
Reference
Description
Price
1
6AH1217000
Camshaft assembly 1
Loading…
↗
2
6AH115370094
Gear, driven
Loading…
↗
3
90105081A7
Bolt, washer based(jn9)
Loading…
↗
4
9020108784
Washer, plate (3l7)
Loading…
↗
5
9020115423
Washer, plate(663)
Loading…
↗
6
6AH1153600
Gear, drive
Loading…
↗
7
6AH1155700
Washer 1
Loading…
↗
8
9017030003
Nut
Loading…
↗
9
9028003M01
Key woodruff 146115450000
Loading…
↗
10
6AH4624100
Belt
Loading…
↗
11
6AH4629700
Cover, dust
Loading…
↗
12
9048010627
Grommet
Loading…
↗
13
6AH4261700
Damper, form
Loading…
↗
14
9048006M19
Grommet (6e3)
Loading…
↗
15
6AH1330000
Oil pump assembly
Loading…
↗
16
6AH1332900
Gasket, pump cover
Loading…
↗
17
9010506035
Bolt, flange
Loading…
↗
18
9310222009
Oil seal
Loading…
↗
19
6AH1343700
マーク , コーシヨン
Loading…
↗
20
6AH8199400
Label, safety
