XF425NSA7 (2018)
BOTTOM COWLING 3
Diagram: BOTTOM COWLING 3
Parts List
Reference
Description
Price
1
6GR4281500CE
WHITE
Lever, clamp 1
Loading…
↗
1
6GR4281500
Lever, Clamp 1
Loading…
↗
1
6GR42815008D
GRAY
Lever, clamp 1
Loading…
↗
2
6GR42816008D
GRAY
Lever, clamp 2
Loading…
↗
2
6GR4281600CE
WHITE
Lever, clamp 2
Loading…
↗
2
6GR4281600
Lever, Clamp 2
Loading…
↗
3
6GR42817008D
GRAY
Lever, clamp 3
Loading…
↗
3
6GR4281700CE
WHITE
Lever, clamp 3
Loading…
↗
3
6GR4281700
Lever, Clamp 3
Loading…
↗
4
6GR4282800
Plate, clamp
Loading…
↗
5
6GR4282900
Plate, clamp 2
Loading…
↗
6
9589506012
Bolt, flange deep recess
Loading…
↗
7
6GR4283500
Pin, set 1
Loading…
↗
8
9024005002
Pin, clevis
Loading…
↗
9
68T4283500
Pin, set 1
Loading…
↗
10
6GR4283300
Washer, plain
Loading…
↗
11
9038615M73
Bush(6l2)
Loading…
↗
12
9020615M18
Washer, wave(6l2)
Loading…
↗
13
90201156J2
Washer, plate(j41)
Loading…
↗
14
6GR4281800
Lever, clamp 4
Loading…
↗
15
6GR4281900
Lever, clamp 5
Loading…
↗
16
9589508012
Bolt, flange deep recess
Loading…
↗
