F40FED (2018)
BRACKET 1
Diagram: BRACKET 1
Parts List
Reference
Description
Price
1
6K943111108D
Bracket, clamp 1
Loading…
↗
2
6BG43112108D
Bracket, clamp 2
Loading…
↗
3
65W4319200
Knob, stopper
Loading…
↗
4
65W4319100
Shaft, stopper
Loading…
↗
5
9169030018
926-51502-00 pin, spring (700)
Loading…
↗
6
9038614MA1
Bush
Loading…
↗
7
6BG43311008D
S(16.3")
Bracket, swivel 1
Loading…
↗
7
6BG43311108D
L(21.1")
Bracket, swivel 1
Loading…
↗
8
9370006M03
Nipple, grease(6a1)
Loading…
↗
9
6K94313101
Bolt, clamp bracket
Loading…
↗
10
9759508520
Bolt(6td)
Loading…
↗
11
9018522043
Nut, self-locking
Loading…
↗
12
9038622MA4
Bush
Loading…
↗
13
9046513M11
Clamp (6e5)
Loading…
↗
14
9024918M35
Pin, lower shock mount
Loading…
↗
15
9708008016
Bolt
Loading…
↗
16
9020108M00
Washer, plate(6e0)
Loading…
↗
17
9038618M44
Bushing (6g5)
Loading…
↗
18
9038618MA0
Bush
Loading…
↗
19
9024912M38
Pin
Loading…
↗
20
9038112M10
Bush, solid
Loading…
↗
21
9038112M11
Bush, solid
Loading…
↗
22
9908010600
Circlip
Loading…
↗
23
9709510050
Bolt, hexagon deep recess
Loading…
↗
24
6BG43654A0
Nut 1
Loading…
↗
25
9299510600
Washer, plate
Loading…
↗
26
65W4525100
Anode
Loading…
↗
27
9010106020
Bolt
Loading…
↗
28
6BG8212700
Wire, lead 2
Loading…
↗
29
9759506514
Bolt(gj3)
Loading…
↗
30
9046510M77
Clamp
Loading…
↗
32
9046508M63
Clamp(61u)
Loading…
↗
33
9708506010
Bolt
Loading…
↗
34
9010112M65
Bolt
Loading…
↗
35
9020112062
Washer, plate
Loading…
↗
36
9020112426
Washe, plate(663)
Loading…
↗
37
9538012600
Nut (707)
