Yamaha Outboard Parts - BRACKET 1 - FT50CED (2003) | Flood Marine

Diagram: BRACKET 1

Diagram

Parts List

Reference
Description
Price


3
63D−82148−00
Wire, lead 5
Loading…

↗
4
97885−06008
Screw, pan head(6a3)
Loading…

↗
5
65W−45251−00
Anode
Loading…

↗
6
90101−06020
Bolt
Loading…

↗
10
93700−06M03
Nipple, grease(6a1)
Loading…

↗
11
63D−43131−01
Bolt, clamp bracket
Loading…

↗
12
90386−22M15
Bushing (688)
Loading…

↗
13
90201−22M03
Washer, plate(64j)
Loading…

↗
14
90185−22M11
Nut, self-locking
Loading…

↗
15
6G5−43145−01
Cap, clamp bracket
Loading…

↗
16
6H5−43181−03
Lever, tilt stop 1
Loading…

↗
17
6H5−43185−03
Lever, tilt stop 2
Loading…

↗
18
90386−10M16
Bushing (688)
Loading…

↗
19
90386−10025
Bushing (658)
Loading…

↗
20
91690−30020
Pin, spring (6h4)
Loading…

↗
21
6G5−43148−00
Collar, distance
Loading…

↗
22
90249−06M19
Pin(6e5)
Loading…

↗
23
90506−14M24
Spring, tension(6e5)
Loading…

↗
24
97095−06010
Bolt
Loading…

↗
25
6G5−43144−00
Hook, spring
Loading…

↗
26
688−43160−01
Tilt rod ass'y
Loading…

↗
27
688−43165−00
Stopper, tilt rod
Loading…

↗
28
91690−30012
Pin, spring
Loading…

↗
29
90502−16M02
Spring, conical (688)
Loading…

↗
30
62Y−43170−10−4D F50A−L
Shock Absorber assembly
Loading…

↗
30
62Y−43170−20−4D FT50C−L
Shock absorber assembly
Loading…

↗
30
64J−43170−00−4D FT50C−X
Shock absorber assembly
Loading…

↗
31
663−45251−00
Anode
Loading…

↗
32
90152−06M01
Screw, countersunk
Loading…

↗
33
63D−43691−00
Indicator, tilt
Loading…

↗
34
69D−43631−00
Lever, tilt
Loading…

↗
35
682−43318−01
Cover
Loading…

↗
37
69D−43126−00
Pin, upper shock mount
Loading…

↗
38
90387−16003
Collar
Loading…

↗
39
90387−16004
Collar
Loading…

↗
40
93410−16006
Circlip
Loading…

↗
41
62Y−43818−00
Pin, lower shock mount
Loading…

↗
42
97080−08016
Bolt
Loading…

↗
43
90201−08M04
Washer, plate(6r8)
Loading…

↗
44
90387−18002
Collar
Loading…

↗
45
90387−18003
Collar
Loading…

↗
46
90101−12M65
Bolt
Loading…

↗
47
92995−12200
Ybs66-12 washer,plain
Loading…

↗
48
90201−12426
Washe, plate(663)
Loading…

↗
49
95380−12600
Nut (707)
Loading…

↗
