225GETO (2002)
BRACKET 2
Diagram: BRACKET 2
Parts List
Reference
Description
Price
1
64E−43139−02
Cam, trim sender (with screw)
Loading…
↗
2
97780−60525
Screw, tapping(65j)
Loading…
↗
3
64E−83672−02
Trim sender
Loading…
↗
4
97885−06016
Screw, pan head(6b0)
Loading…
↗
5
90465−11M10
Clamp
Loading…
↗
6
93210−37MH7
O-ring(61u)
Loading…
↗
7
90202−40M47
Washer, plate(61a)
Loading…
↗
8
64E−43376−00
Bolt, thrust receiver
Loading…
↗
9
95780−10300
Nut, nylon (6e5)
Loading…
↗
10
66K−42510−00−8D
Steering bracket assembly
Loading…
↗
11
90201−38M60
Washer, plate (6e5)
Loading…
↗
12
90386−38M32
Bush(6e5)
Loading…
↗
13
66K−44551−00−8D
Housing, lower mount rubber
Loading…
↗
14
93410−37M04
Circlip (6e5)
Loading…
↗
15
6E5−44575−00
Damper, lower mount rubber
Loading…
↗
16
66K−44555−00−94
Mount damper, lower side
Loading…
↗
17
90202−32M19
Washer, plate (6e5)
Loading…
↗
18
90201−16M55
Washer, plate (6e5)
Loading…
↗
19
90109−14M80
Bolt
Loading…
↗
20
90201−15M58
Washer, plate (6e5)
Loading…
↗
21
95380−14800
Nut, crown (6e5)
Loading…
↗
22
92995−14600
Washer (6e5)
Loading…
↗
23
90101−10M70
Bolt(6j9)
Loading…
↗
24
66K−44553−00−NA
Cover, lower mount
Loading…
↗
25
65N−43155−N0
Mark 1
Loading…
↗
26
65N−43156−N0
Mark 2
Loading…
↗
27
66K−44514−00−94
Mount damper, upper side
Loading…
↗
28
90201−16M01
Washer, plate(61a)
Loading…
↗
29
90202−28M46
Washer, plate(61a)
Loading…
↗
30
90201−28M01
Washer, plate(61a)
Loading…
↗
31
90109−14M10
Bolt
Loading…
↗
32
90185−14M00
Nut, self-locking(61a)
Loading…
↗
34
61A−44511−00−94
Cover, upper mount
Loading…
↗
35
97095−10045
Bolt(64d)
Loading…
↗
36
92995−10600
Washer, plate
Loading…
↗
