40GWH (2003)
BRACKET 2
Diagram: BRACKET 2
Parts List
Reference
Description
Price
1
90249−12M27
Pin(6f6)
Loading…
↗
2
676−43132−00
Washer, friction 1
Loading…
↗
3
90202−12M01
Washer, plate (676)
Loading…
↗
4
90206−12M00
Washer, wave (676)
Loading…
↗
5
6F5−43627−80
Stopper 1
Loading…
↗
6
6F5−43628−80
Stopper 2
Loading…
↗
7
90249−12M13
Pin (6f5)
Loading…
↗
8
676−43191−00
Shaft, stopper
Loading…
↗
9
93430−10M00
Circlip
Loading…
↗
10
90202−06M00
Washer, plate (676)
Loading…
↗
11
90501−14M05
Spring, compression (676)
Loading…
↗
12
6F5−43630−80
Tilt lever assembly
Loading…
↗
13
676−43631−00
Lever, tilt 1
Loading…
↗
14
97095−05010
Bolt (682)
Loading…
↗
15
90508−14M00
Spring, torsion (676)
Loading…
↗
16
676−43616−00
Rod, tilt lock 1
Loading…
↗
17
663−43318−00
Cover
Loading…
↗
18
676−43614−00
Plate, tilt lock 1
Loading…
↗
19
676−43615−00
Plate, tilt lock 2
Loading…
↗
20
676−43613−00
Arm, tilt lock
Loading…
↗
21
90249−07M01
Pin (676)
Loading…
↗
22
90249−07M02
Pin (676)
Loading…
↗
23
90506−30M00
Spring, tension (676)
Loading…
↗
24
91490−20012
Pin, cotter (648)
Loading…
↗
25
90387−07M04
Collar (676)
Loading…
↗
26
676−43160−02
Tilt rod assembly
Loading…
↗
27
676−43165−00
Stopper plate, titl lock rod
Loading…
↗
28
91690−30010
Pin, spring (663)
Loading…
↗
29
90502−10M04
Spring, conical(6f5)
Loading…
↗
30
676−43643−00
Spring
Loading…
↗
31
90269−04M00
Rivet (676)
Loading…
↗
