E40XMH (2002)
CARBURETOR
Diagram: CARBURETOR
Parts List
Reference
Description
Price
1
66T1430112
Carburetor assembly 1
Loading…
↗
1
66T--14301--02
Carburetor assembly 1
Loading…
↗
2
66T--14578--00
Collar
Loading…
↗
3
66T--14584--00
Stopper
Loading…
↗
4
6J8--14592--01
Screw
Loading…
↗
5
92990--05600
Washer, plain (646)
Loading…
↗
6
66T--14384--01
Gasket, float chamber
Loading…
↗
7
66T--14536--00
Gasket
Loading…
↗
8
66T--14527--00
Plate
Loading…
↗
9
97980--04112
Screw, pan head (686)
Loading…
↗
10
66T--14523--00
Screw, stop
Loading…
↗
11
6J8--14334--00
Spring, throttle
Loading…
↗
12
6E5--14323--03
Screw, air adjusting
Loading…
↗
13
6E5--14223--00
Spring, air adjusting
Loading…
↗
14
66T--14945--02
Spacer assembly (#38)
Loading…
↗
15
61A--1492E--85
Jet, main (#170)
Loading…
↗
16
6E5--14546--00
Valve, needle
Loading…
↗
17
6E5--14159--00
Clip
Loading…
↗
18
6E5--14385--02
Float
Loading…
↗
19
6E5--14386--02
Pin, float
Loading…
↗
20
66T--1492F--35
Jet, air slow (#70)
Loading…
↗
21
66T--14984--00
Gasket, float chamber
Loading…
↗
22
66T--14992--00
Plug
Loading…
↗
23
66T--14981--00
Body, float chamber
Loading…
↗
24
66T--14991--00
Plug, drain
Loading…
↗
25
66T--14959--00
Gasket
Loading…
↗
26
97980--05125
Screw, panhead (a93)
Loading…
↗
