Yamaha Outboard Parts - CARBURETOR - FT8DMH (2002) | Flood Marine

Diagram: CARBURETOR

Diagram

Parts List

Reference
Description
Price


1
68T−14301−30
Carburetor assembly 1
Loading…

↗
1
68T−14301−20 FOR SAV
Carburetor & accel link 68t20
Loading…

↗
1
68T−14301−50 FOR SAV
Carburetor & accel link 68t50
Loading…

↗
1
68T−14301−00
Carburetor & accel link 68t00
Loading…

↗
2
6E5−14321−00
Screw, throttle
Loading…

↗
3
6J8−14334−00
Spring, throttle
Loading…

↗
4
97980−04112
Screw, pan head (686)
Loading…

↗
5
68T−14385−00
Float
Loading…

↗
6
67D−14966−00
Rubber cap
Loading…

↗
7
67D−14386−00
Pin, float
Loading…

↗
8
68T−14546−00
Valve, needle
Loading…

↗
9
68T−1492E−37
Jet, main (#74)
Loading…

↗
10
68T−1492F−1K
Jet, air slow (#39)
Loading…

↗
11
68T−1492A−00
Nozzle, main
Loading…

↗
12
67D−14984−00
Gasket, float chamber
Loading…

↗
13
68T−14981−00
Body, float chamber
Loading…

↗
14
6J8−14959−00
Gasket, drin screw
Loading…

↗
15
66T−14991−00
Plug, drain
Loading…

↗
16
67D−14323−00
Screw, air adjusting
Loading…

↗
16
68T−14323−20 FOR SAV
Screw, Air Adjusting
Loading…

↗
17
67D−14536−00
Gasket
Loading…

↗
18
67D−14527−00
Plate
Loading…

↗
19
68T−14126−00
Plug
Loading…

↗
