60FET (2003)
CARBURETOR 1
Diagram: CARBURETOR 1
Parts List
Reference
Description
Price
1
6H2−14301−10
Carburetor assembly 1
Loading…
↗
2
6H2−14302−10
Carburetor assembly 2
Loading…
↗
3
6H2−14303−10
Carburetor assembly 3
Loading…
↗
4
6H3−14947−07
Jet, Needle
Loading…
↗
5
676−14943−35
#1,2
Jet, main (#140)
Loading…
↗
5
676−14943−36
#3
Jet, main (#145)
Loading…
↗
6
6H2−14948−155
Jet (#70)
Loading…
↗
7
676−14966−00
Rubber cap
Loading…
↗
8
6H3−14590−01
Needle valve assembly
Loading…
↗
9
663−14159−00
Clip
Loading…
↗
10
676−14186−00
Pin, valve
Loading…
↗
11
98502−04008
Screw, pan head (713)
Loading…
↗
12
6G1−14985−00
Float comp.
Loading…
↗
13
688−14548−00
Pin, arm
Loading…
↗
14
6G1−14984−00
Gasket, float chamber
Loading…
↗
15
6H2−14980−00
Body, float chamber
Loading…
↗
16
97980−04114
Screw, pan head(ga5)
Loading…
↗
17
6H3−14992−00
Screw, drain
Loading…
↗
18
93210−04230
O-ring (371)
Loading…
↗
19
663−14126−00
Packing
Loading…
↗
20
663−14527−00
Plate
Loading…
↗
21
688−14126−00
Packing
Loading…
↗
22
688−14527−00
Plate
Loading…
↗
23
6H2−14527−01
Plate
Loading…
↗
24
97980−05310
Screw, with washer(6k5)
Loading…
↗
25
692−14923−00
Screw, adjusting
Loading…
↗
26
679−14555−00
Spring
Loading…
↗
27
6K5−14592−00
#1,2
Screw
Loading…
↗
28
90201−05652
#1,2
Washer, plate(65j)
Loading…
↗
29
63V−14523−00
#2
Screw, stop
Loading…
↗
30
90501−10326
#2
Spring coil(663)(carb)
Loading…
↗
31
6H3−17578−00
#3
Collar
Loading…
↗
32
6H3−14578−00
Collar
Loading…
↗
33
93210−15M52
O-ring (6e9)
Loading…
↗
34
93210−04228
O-ring (371)
Loading…
↗
