85AET (2003)
CONTROL
Diagram: CONTROL
Parts List
Reference
Description
Price
1
663--48531--00
Bracket, remote control
Loading…
↗
2
663--48538--00
Clamp, cable 1
Loading…
↗
3
91690--30012
Pin, spring
Loading…
↗
4
97095--08016
Bolt, hexagon deep recess
Loading…
↗
5
92995--08100
Ybs67-8 washer, spring
Loading…
↗
6
663--48344--00
Cable end, remote control
Loading…
↗
7
688416320194
Lever, magneto control
Loading…
↗
8
662--41214--01
Joint 1
Loading…
↗
9
90468--18008
Clip 620436610000
Loading…
↗
10
97095--08045
Bolt, hexagon
Loading…
↗
11
90201--08M23
Washer, plate (6e5)
Loading…
↗
12
90386--12089
Bushing(663)
Loading…
↗
13
90387--08M16
14 −
Loading…
↗
14
90386--22M13
Bushing (688)
Loading…
↗
15
90202--12092
Washer, plate(663)
Loading…
↗
16
90201--08M13
Washer plate (682)
Loading…
↗
17
90508--29M05
Spring, torsion (688)
Loading…
↗
18
688416310194
Lever, magneto control
Loading…
↗
19
663--85518--00
Joint, ball
Loading…
↗
20
95303--05700
Nut (656)
Loading…
↗
21
90157--06013
Screw, pan head(697)
Loading…
↗
22
688--44194--00
Cap
Loading…
↗
23
95303--06600
Nut(661)
Loading…
↗
24
90501--16M12
Spring, compression (688)
Loading…
↗
25
682--41237--50
Joint, link 2
Loading…
↗
26
95380--05600
Nut, hexagon (663)
Loading…
↗
27
682--41237--00
Joint, link 2
Loading…
↗
28
688--41211--01
Link, accel
Loading…
↗
31
6884121300
Cam, accel.
Loading…
↗
32
90387--06M17
Collar, lever 1
Loading…
↗
33
90206--10M04
Washer, wave (676)
Loading…
↗
34
90119--06M24
Bolt, with washer
Loading…
↗
35
688--44117--00--94
Bracket 1
Loading…
↗
36
97013--06020
Bolt(62y)
Loading…
↗
37
92903--06600
Washer, plain (646)
Loading…
↗
38
688--44124--00
Link, shift rod
Loading…
↗
39
688--44122--00
Bushing, shift rod lever
Loading…
↗
40
90202--07M07
Washer, plate (688)
Loading…
↗
42
6884412102
Lever, shift rod
Loading…
↗
42
6H1--44121--00
85A−FOR MALAYSIA,
Lever, shift rod 1
Loading…
↗
43
90386--06M12
EXCEPT 85A−FOR
Bushing (688)
Loading…
↗
44
688441180094
Bracket
Loading…
↗
45
97013--08030
Bolt
Loading…
↗
46
92903--08100
Ybs67-8 washer, spring
Loading…
↗
47
92903--08600
Washer, plain (663)
Loading…
↗
48
93501--04M02
Ball (697)
Loading…
↗
49
90501--12082
Spring 6484411600
Loading…
↗
50
648--42715--00
Bushing 2
Loading…
↗
51
6884412012
L
Handle gear shift assembly
Loading…
↗
51
6H1--44120--12
L 85A−FOR MALAYSIA,
Handle gear shift assembly
Loading…
↗
51
6884412022
X
Handle gear shift assembly
Loading…
↗
51
6924412032
Y
Handle Gear Shift assembly
Loading…
↗
52
6964414700
EXCEPT 85A−FOR
Boot, shift rod
Loading…
↗
53
9038608006
Bushing (688)
Loading…
↗
53
90386--07M58
85A−FOR MALAYSIA,
Bush(6h1)
Loading…
↗
54
92990--08200
Ybs66-8 washer, plain
Loading…
↗
56
6974366200
EXCEPT 85A−FOR
Guide, reverse rod
Loading…
↗
