FT25BED (2002)
CONTROL
Diagram: CONTROL
Parts List
Reference
Description
Price
1
6H3--48538--00
Clamp, cable
Loading…
↗
2
65W--44121--00
Lever, shift rod
Loading…
↗
3
65W--44122--00
15 −
Loading…
↗
4
90254--03M05
Pin, spring
Loading…
↗
5
6F5--41662--00
Bracket 2
Loading…
↗
6
90109--06M81
Bolt
Loading…
↗
7
65W--44116--00
Spring
Loading…
↗
8
90109--06M86
Bolt
Loading…
↗
9
68U4414310
Rod, shift
Loading…
↗
10
90468--18008
Clip 620436610000
Loading…
↗
11
65W--44142--00
Joint
Loading…
↗
13
68U4412500
-
Loading…
↗
14
90387--06M29
Coller (6a0)
Loading…
↗
15
90201--06M31
Washer (6a0)
Loading…
↗
16
97095--06025
Bolt
Loading…
↗
17
92995--06600
Washer, plain (646)
Loading…
↗
18
65W--44192--00
Joint, rod 1
Loading…
↗
19
90201--05M06
Washer, plate(61u)
Loading…
↗
20
90468--10005
Pin, hair 6264123500
Loading…
↗
22
663--48344--00
Cable end, remote control
Loading…
↗
24
68U4163800
Pulley
Loading…
↗
25
65W--41283--00
Lever, free accel.
Loading…
↗
26
661--41262--02
Joint, choke lever
Loading…
↗
27
90387--06M08
Collar
Loading…
↗
28
65W4121100
Link, Accel.
Loading…
↗
29
65W--14497--01
Stay, Throttle Wire
Loading…
↗
31
97095--06055
Bolt, hexagon w/w deep recess
Loading…
↗
33
97095--06010
Bolt
Loading…
↗
