F4AMH (2003)
CRANKSHAFT. PISTON
Diagram: CRANKSHAFT. PISTON
Parts List
Reference
Description
Price
1
67D−11400−00
Crankshaft assembly
Loading…
↗
2
90201−266P2
Washer, plate(ja8)
Loading…
↗
3
67D−11650−00
Connecting rod kit
Loading…
↗
4
67D−11654−00
Bolt, connecting rod
Loading…
↗
5
68D−E1631−00−96
Piston (std)
Loading…
↗
5
68D−E1635−00
AP
3−
Loading…
↗
5
68D−E1636−00
AP
3−
Loading…
↗
6
68D−E1603−00
Piston ring (set)
Loading…
↗
6
68D−E1604−00
AP
3−
Loading…
↗
6
68D−E1605−00
AP
3−
Loading…
↗
7
68D−E1633−00
3−
Loading…
↗
8
93450−14088
Circlip (22f)
Loading…
↗
