F40NET (2025)
CYLINDER & CRANKCASE 2
Diagram: CYLINDER & CRANKCASE 2
Parts List
Reference
Description
Price
1
6CJW009A029S
Cylinder head complete
Loading…
↗
2
6CJ11111109S
Head, cylinder 1
Loading…
↗
3
6AH1113310
Guide, valve 1
Loading…
↗
4
6G81132500
Anode
Loading…
↗
5
9898005025
Screw, panhead (a93)
Loading…
↗
6
6G811197A0
Plug, blind
Loading…
↗
7
9321013M63
O-ring (6g8)
Loading…
↗
8
9010906M65
Bolt(62y)
Loading…
↗
9
9043006014
Gasket 256113960000
Loading…
↗
10
6CJ1118100
Gasket, cylinder head 1
Loading…
↗
11
9953008012
Pin, dowel(6g8)
Loading…
↗
12
9010509009
Bolt, flange
Loading…
↗
13
9011906MA6
Bolt, with washer
Loading…
↗
14
6CJ11191009S
Cover, cylinder head 1
Loading…
↗
15
6C51116800
Cover, breather
Loading…
↗
16
9760704210
Screw, pan head with washer
Loading…
↗
17
6CJ1135600
Seal, cylinder 2
Loading…
↗
18
97E9506520
Bolt, hexagon w/w deep recess
Loading…
↗
19
6CJ1111900
Hanger, engine
Loading…
↗
21
6CJ1119200
Cover, cylinder head 2
Loading…
↗
22
9048012314
Grommet(3aa)
Loading…
↗
23
6G81536300
Plug, oil
Loading…
↗
24
9321024M79
O-ring
Loading…
↗
25
9470200429
Plug, spark (ngk lkr7e)
Loading…
↗
