FL115BET (2018)
CYLINDER & CRANKCASE 2
Diagram: CYLINDER & CRANKCASE 2
Parts List
Reference
Description
Price
1
6EKW009A009S
Cylinder head complete
Loading…
↗
2
6EK11110009S
Cylinder head assembly
Loading…
↗
3
6DA1113310
Guide, valve 1
Loading…
↗
4
9034018M09
Plug, straight screw
Loading…
↗
5
90201186F1
Washer, plate (22f)
Loading…
↗
6
9011907235
Bolt, with washer
Loading…
↗
7
9180908006
Pin, dowel
Loading…
↗
8
9011907234
Bolt, with washer
Loading…
↗
9
9034014M06
Plug, straight screw(62y)
Loading…
↗
10
9043014115
Gasket (663)
Loading…
↗
11
6G81132500
Anode
Loading…
↗
12
9898005025
Screw, panhead (a93)
Loading…
↗
13
6G811197A0
Plug, blind
Loading…
↗
14
9321013M63
O-ring (6g8)
Loading…
↗
15
69J1130100
Anode cover assembly
Loading…
↗
16
67F1132501
Anode
Loading…
↗
17
67F1132800
Grommet, anode
Loading…
↗
18
9010506M07
Bolt (689)
Loading…
↗
19
9043006M03
Gasket (6f5)
Loading…
↗
20
9587508040
Bolt, flange deep recess
Loading…
↗
21
6EK1118100
Gasket, cylinder head 1
Loading…
↗
22
9953014016
Pin, dowel
Loading…
↗
23
9015510008
Screw, flat fillister
Loading…
↗
24
9010506037
Bolt, flange
Loading…
↗
25
6EK1119100
Cover, cylinder head 1
Loading…
↗
26
6EK1116800
Cover, breather
Loading…
↗
27
9760704208
Screw, pan head with washer
Loading…
↗
28
6EK1119300
Gasket, head cover 1
Loading…
↗
29
9589506030
Bolt, flange deep recess
Loading…
↗
30
6EK1119200
Cover, cylinder head 2
Loading…
↗
31
9048012314
Grommet(3aa)
Loading…
↗
32
6EK1111900
Hanger, engine
Loading…
↗
33
9589508020
Bolt, flange deep recess
Loading…
↗
34
6G81536300
Plug, oil
Loading…
↗
35
9321024M79
O-ring
Loading…
↗
36
9470200437
Plug, spark (lkr6e)
Loading…
↗
