Diagram: CYLINDER & CRANKCASE 2

Diagram

Parts List

Reference
Description
Price


1
65WW009A161S
Cylinder Head assembly
Loading…

↗
2
65W11111201S
-
Loading…

↗
3
62Y1113330
Guide, valve 1
Loading…

↗
4
9345009M01
Circlip (6g8)
Loading…

↗
5
62Y1132500
Anode
Loading…

↗
6
66M1132800
Grommet, anode
Loading…

↗
7
66M113270094
Cover, anode
Loading…

↗
8
66M1253500
Plate
Loading…

↗
9
9709505012
Bolt, hexagon
Loading…

↗
10
9299505600
Washer, plain (646)
Loading…

↗
11
9709506020
Bolt(7u8)
Loading…

↗
12
9299506600
Washer, plain (646)
Loading…

↗
13
9043006014
Gasket 256113960000
Loading…

↗
14
9010906M65
Bolt(62y)
Loading…

↗
15
65W1118130
Gasket, cylinder head 1
Loading…

↗
16
9953008012
Pin, dowel(6g8)
Loading…

↗
17
9011909M00
Bolt, with washer(62y)
Loading…

↗
18
9011906MA3
Bolt, with washer
Loading…

↗
19
65W11191001S
-
Loading…

↗
20
65W1135600
Seal, cylinder 2
Loading…

↗
23
6G81536300
Plug, oil
Loading…

↗
24
9321024M79
O-ring
Loading…

↗
25
62Y1213860
Mark, Caution
Loading…

↗
26
9470100375
Plug, spark (dpr6ea-9)(62y)
Loading…

↗
