FT60BET (2006)
CYLINDER & CRANKCASE 2
Diagram: CYLINDER & CRANKCASE 2
Parts List
Reference
Description
Price
1
69WW009A001S
Cylinder head complete
Loading…
↗
2
69W11111001S
Head, cylinder 1
Loading…
↗
3
62Y1113330
Guide, valve 1
Loading…
↗
4
9345009M01
Circlip (6g8)
Loading…
↗
5
62Y1132500
Anode
Loading…
↗
6
66M1132800
Grommet, anode
Loading…
↗
7
66M113270094
Cover, anode
Loading…
↗
8
66M1253500
Plate
Loading…
↗
9
9709505012
Bolt, hexagon
Loading…
↗
10
9299505600
Washer, plain (646)
Loading…
↗
11
9709506020
Bolt(7u8)
Loading…
↗
12
9299506600
Washer, plain (646)
Loading…
↗
13
9709506010
Bolt
Loading…
↗
14
9043006014
Gasket 256113960000
Loading…
↗
15
9010906M65
Bolt(62y)
Loading…
↗
17
69W1118101
Gasket, cylinder head 1
Loading…
↗
18
9953008012
Pin, dowel(6g8)
Loading…
↗
19
9011909M00
Bolt, with washer(62y)
Loading…
↗
20
9011906MA3
Bolt, with washer
Loading…
↗
21
62Y11191011S
Cover, cylinder head 1
Loading…
↗
22
62Y1448500
Pipe, joint
Loading…
↗
23
62Y1116800
Cover, breather
Loading…
↗
24
9850704010
Screw, pan head(6g8)
Loading…
↗
25
9290704600
Washer(jf2)
Loading…
↗
26
62Y1135600
Seal, cylinder 2
Loading…
↗
29
62Y1111900
Hanger, engine
Loading…
↗
32
9043008143
Gasket (256-11198-00)
Loading…
↗
33
9709508014
Bolt, hexagon deep recess
Loading…
↗
34
6G81536300
Plug, oil
Loading…
↗
35
9321024M79
O-ring
Loading…
↗
36
62Y1213860
Mark, Caution
Loading…
↗
37
9470100406
Plug, spark (dpr5ea-9)
Loading…
↗
