VF90B (2025)
CYLINDER & CRANKCASE 2
Diagram: CYLINDER & CRANKCASE 2
Parts List
Reference
Description
Price
1
6FPW009A109S
Cylinder head complete
Loading…
↗
2
6FPW1111009S
Head, cylinder 1
Loading…
↗
3
6DA1113310
Guide, valve 1
Loading…
↗
4
9034099001
Plug, straight screw
Loading…
↗
5
9321014579
O-ring (26h)
Loading…
↗
6
9034097002
Plug, straight screw
Loading…
↗
7
9321018322
O-ring (1l9)
Loading…
↗
8
9034027001
Plug, straight screw
Loading…
↗
9
9034014M06
Plug, straight screw(62y)
Loading…
↗
10
9043014115
Gasket (663)
Loading…
↗
11
6G81132500
Anode
Loading…
↗
12
9898005025
Screw, panhead (a93)
Loading…
↗
13
6G811197A0
Plug, blind
Loading…
↗
14
9321013M63
O-ring (6g8)
Loading…
↗
15
9010906M65
Bolt(62y)
Loading…
↗
16
9043006014
Gasket 256113960000
Loading…
↗
17
6FP1118100
Gasket, cylinder head 1
Loading…
↗
18
9953014016
Pin, dowel
Loading…
↗
19
9014910072
Screw
Loading…
↗
20
9010508220
Bolt, flange
Loading…
↗
21
9010508175
Bolt, flange
Loading…
↗
22
6FP1119100
Cover, cylinder head 1
Loading…
↗
23
6FP1116800
Cover, breather
Loading…
↗
24
9760704208
Screw, pan head with washer
Loading…
↗
25
6FP1119300
Gasket, head cover 1
Loading…
↗
26
95D9506030
Bolt, flange deep recess
Loading…
↗
27
6FP1119200
Cover, cylinder head 2
Loading…
↗
28
9048012314
Grommet(3aa)
Loading…
↗
29
6CJ1342800
Bracket, strainer 1
Loading…
↗
30
97E9506516
Bolt, hexagon w/w deep recess
Loading…
↗
31
6G81536300
Plug, oil
Loading…
↗
32
9321024M79
O-ring
Loading…
↗
33
9470200440
Plug, spark (ngk lkr6e 9n)
Loading…
↗
