XF425NSB2 (2020)
CYLINDER & CRANKCASE 2
Diagram: CYLINDER & CRANKCASE 2
Parts List
Reference
Description
Price
1
6GRW009A009S
Cylinder head complete
Loading…
↗
2
6GR1111000
Cylinder head assembly
Loading…
↗
3
6DA1113310
Guide, valve 1
Loading…
↗
4
9034451019
Plug, taper screw
Loading…
↗
5
9034097002
Plug, straight screw
Loading…
↗
6
9321018322
O-ring (1l9)
Loading…
↗
7
9180908006
Pin, dowel
Loading…
↗
8
9011907235
Bolt, with washer
Loading…
↗
9
9011907234
Bolt, with washer
Loading…
↗
10
9169040018
Pin spring(664)
Loading…
↗
11
6GRW009C009S
Cylinder head 2 complete
Loading…
↗
12
6GR1112000
Cylinder head assembly 2
Loading…
↗
21
6GR1119700
Plug, blind
Loading…
↗
22
9321019216
O-ring
Loading…
↗
23
6AW1132L00
Anode 2
Loading…
↗
24
9878005025
Ybs53-525 screw,flat head
Loading…
↗
25
6GR1118100
Gasket, cylinder head 1
Loading…
↗
26
9038711005
Collar
Loading…
↗
27
9014911001
Screw
Loading…
↗
28
9010508220
Bolt, flange
Loading…
↗
29
9010508175
Bolt, flange
Loading…
↗
30
9470200442
Plug, spark (ngk ilmar7e9)
Loading…
↗
