FL225FET (2013)
CYLINDER & CRANKCASE 3
Diagram: CYLINDER & CRANKCASE 3
Parts List
Reference
Description
Price
9
9588506014
Go to P/N)PE0-OM-130048
Bolt, flange deep recess
Loading…
↗
11
item_description
Loading…
↗
1
6CB8612000
Solenoid valve assembly
Loading…
↗
2
6CB1242F00
Gasket, filter
Loading…
↗
3
9010506035
Bolt, flange
Loading…
↗
4
6CB1554400
Stay 1
Loading…
↗
5
9010508178
Bolt, flange
Loading…
↗
6
6CB1135A00
Bracket
Loading…
↗
7
9010506037
Bolt, flange
Loading…
↗
8
6CB1514200
Guide 1
Loading…
↗
10
6P28578000
Sensor, knock
Loading…
↗
