Yamaha Outboard Parts - CYLINDER & CRANKCASE 3 - FL350AET (2013) | Flood Marine

Diagram: CYLINDER & CRANKCASE 3

Diagram

Parts List

Reference
Description
Price


1
6AW1118610
Cover, cylinder head side 2
Loading…

↗
2
9048012314
Grommet(3aa)
Loading…

↗
3
6AW1118710
Cover, cylinder head side 3
Loading…

↗
5
6CB8612000
Solenoid valve assembly
Loading…

↗
6
6CB1242F00
Gasket, filter
Loading…

↗
7
9010506035
Bolt, flange
Loading…

↗
8
6AW1135A00
Bracket
Loading…

↗
9
9010508240
Bolt, flange
Loading…

↗
10
6P28578000
Sensor, knock
Loading…

↗
