XF375NSA (2018)
CYLINDER & CRANKCASE 3
Diagram: CYLINDER & CRANKCASE 3
Parts List
Reference
Description
Price
1
6GR11191009S
Cover, cylinder head 1
Loading…
↗
2
6GR1113500
Plate, breather 3
Loading…
↗
3
9760704208
Screw, pan head with washer
Loading…
↗
4
6GR1119300
Gasket, head cover 1
Loading…
↗
5
9589506030
Bolt, flange deep recess
Loading…
↗
6
6GR11192009S
Cover, cylinder head 2
Loading…
↗
7
6GR1137200
Nipple, hose
Loading…
↗
8
9321028646
O-ring (7or)
Loading…
↗
9
9589506025
Bolt, flange deep recess
Loading…
↗
10
6GR1113600
Plate, breather 4
Loading…
↗
12
6GR1119400
Gasket, head cover 2
Loading…
↗
14
6GR8612000
Solenoid valve assembly
Loading…
↗
15
6CB1242F00
Gasket, filter
Loading…
↗
16
9010506035
Bolt, flange
Loading…
↗
17
6GR8231600
Bracket, ignition coil
Loading…
↗
18
9011006038
Bolt, hexagon socket head
Loading…
↗
19
6GR1192700
Lifter
Loading…
↗
20
6GR4274300
Bracket
Loading…
↗
21
9589506020
Bolt, flange(jk3)
Loading…
↗
