Z250FETO (2004)
CYLINDER & CRANKCASE 3
Diagram: CYLINDER & CRANKCASE 3
Parts List
Reference
Description
Price
1
60V411130094
Outer cover, exhaust
Loading…
↗
2
6761137200
Nipple, hose
Loading…
↗
3
60V4111200
Gasket, exhaust inner cover
Loading…
↗
4
60V4126700
Bushing, joint
Loading…
↗
5
9011906MA3
Bolt, with washer
Loading…
↗
6
60V113270094
Anode cover assembly
Loading…
↗
7
67F1132500
Anode
Loading…
↗
8
9707506020
Bolt(7u8)
Loading…
↗
9
9299506600
Washer, plain (646)
Loading…
↗
10
67F1132800
Grommet, anode
Loading…
↗
11
9707508030
Bolt, hexagon (fj1)
Loading…
↗
12
9299508600
Washer, plain (663)
Loading…
↗
13
9046708004
Clip, pipe 6162435600
Loading…
↗
14
6G51241600
Valve, pressure control
Loading…
↗
15
9050116M11
Spring, compression (688)
Loading…
↗
16
9048020M05
Grommet (688)
Loading…
↗
17
60V11382A0
Gasket 2
Loading…
↗
18
6G511372001S
Cover, bypass 2
Loading…
↗
19
9011906MA2
Bolt, with washer
Loading…
↗
20
61A1257600
Hose 1
Loading…
↗
21
9046513M18
Clamp
Loading…
↗
