F15AEP (2003)
CYLINDER. CRANKCASE 2
Diagram: CYLINDER. CRANKCASE 2
Parts List
Reference
Description
Price
3
66M−11133−10
4−
Loading…
↗
4
93450−09M01
Circlip (6g8)
Loading…
↗
5
66M−11181−00
Gasket, cylinder head 1
Loading…
↗
6
99510−10114
Pin, dowel(3vd)
Loading…
↗
7
90105−08M78
Bolt, washer based
Loading…
↗
8
90119−06MA3
Bolt, with washer
Loading…
↗
10
66M−11356−00
Seal, cylinder 2
Loading…
↗
11
97095−06020
Bolt(7u8)
Loading…
↗
12
92995−06600
Washer, plain (646)
Loading…
↗
13
6G8−15363−00
Plug, oil
Loading…
↗
14
93210−24M79
O-ring
Loading…
↗
15
66M−12138−60
Mark, Caution
Loading…
↗
16
94701−00375
Plug, spark (dpr6ea-9)(62y)
Loading…
↗
