F225AET (2003)
CYLINDER. CRANKCASE 2
Diagram: CYLINDER. CRANKCASE 2
Parts List
Reference
Description
Price
3
69J1113310
Guide, intake valve
Loading…
↗
3
69J−11133−10
Guide, intake valve
Loading…
↗
4
90344--51019
Plug, taper screw
Loading…
↗
4
90344−51019
Plug, taper screw
Loading…
↗
5
91809--08006
Pin, dowel
Loading…
↗
5
91809−08006
Pin, dowel
Loading…
↗
6
90119--07235
Bolt, with washer
Loading…
↗
6
90119−07235
Bolt, with washer
Loading…
↗
7
90119--07234
Bolt, with washer
Loading…
↗
7
90119−07234
Bolt, with washer
Loading…
↗
15
67F1132500
Anode
Loading…
↗
15
67F−11325−00
Anode
Loading…
↗
17
97075--06020
Bolt(7u8)
Loading…
↗
17
97075−06020
Bolt(7u8)
Loading…
↗
18
92995--06600
Washer, plain (646)
Loading…
↗
18
92995−06600
Washer, plain (646)
Loading…
↗
19
67F--11328--00
Grommet, anode
Loading…
↗
19
67F−11328−00
Grommet, anode
Loading…
↗
20
97575--08540
Bolt, hexagon w/w deep recess
Loading…
↗
20
97575−08540
Bolt, hexagon w/w deep recess
Loading…
↗
21
69J1118101
Gasket, cylinder head 1
Loading…
↗
21
69J−11181−01
Gasket, cylinder head 1
Loading…
↗
22
9038710M08
Pin, dowel
Loading…
↗
22
90387−10M08
Pin, dowel
Loading…
↗
23
9015510001
Screw, flat fillister
Loading…
↗
23
90155−10001
Screw, flat fillister
Loading…
↗
24
90119--08M91
Bolt, with washer
Loading…
↗
24
90119−08M91
Bolt, with washer
Loading…
↗
25
90119--08021
Bolt, with washer
Loading…
↗
25
90119−08021
Bolt, with washer
Loading…
↗
26
69J1118201
Gasket, cylinder head 2
Loading…
↗
26
69J−11182−01
Gasket, cylinder head 2
Loading…
↗
31
69J11191001S
Cover, cylinder head 1
Loading…
↗
31
69J−11191−00−1S
Cover, cylinder head 1
Loading…
↗
32
69J1113500
Plate, breather 3
Loading…
↗
32
69J−11135−00
Plate, breather 3
Loading…
↗
33
98507--04008
Screw, pan head(jg1)
Loading…
↗
33
98507−04008
Screw, pan head(jg1)
Loading…
↗
34
92907--04600
Washer(jf2)
Loading…
↗
34
92907−04600
Washer(jf2)
Loading…
↗
35
69J1119300
Gasket, head cover 1
Loading…
↗
35
69J−11193−00
Gasket, head cover 1
Loading…
↗
36
97095--06030
Bolt(jf7)
Loading…
↗
36
97095−06030
Bolt(jf7)
Loading…
↗
38
69J11192001S
-
Loading…
↗
38
69J−11192−00−1S
Cover, Cylinder Head 2
Loading…
↗
39
69J1119400
Gasket, head cover 2
Loading…
↗
39
69J−11194−00
Gasket, head cover 2
Loading…
↗
42
94702--00391
Plug, spark (lfr5a-11)
Loading…
↗
42
94702−00391
Plug, spark (lfr5a-11)
Loading…
↗
