F40CET (2002)
CYLINDER. CRANKCASE 2
Diagram: CYLINDER. CRANKCASE 2
Parts List
Reference
Description
Price
3
62Y−11133−30
Guide, valve 1
Loading…
↗
4
93450−09M01
Circlip (6g8)
Loading…
↗
5
62Y−11325−00
Anode
Loading…
↗
6
66M−11328−00
Grommet, anode
Loading…
↗
8
66M−12535−00
Plate
Loading…
↗
9
97095−05012
Bolt, hexagon
Loading…
↗
10
92995−05600
Washer, plain (646)
Loading…
↗
11
97095−06020
Bolt(7u8)
Loading…
↗
12
92995−06600
Washer, plain (646)
Loading…
↗
13
97095−06010
Bolt
Loading…
↗
14
90430−06014
Gasket 256113960000
Loading…
↗
15
90109−06M65
Bolt(62y)
Loading…
↗
17
69W−11181−00
Gasket, cylinder head 1
Loading…
↗
18
99530−08012
Pin, dowel(6g8)
Loading…
↗
19
90119−09M00
Bolt, with washer(62y)
Loading…
↗
20
90119−06MA3
Bolt, with washer
Loading…
↗
22
62Y−14485−00
Pipe, joint
Loading…
↗
23
62Y−11168−00
Cover, breather
Loading…
↗
24
98507−04010
Screw, pan head(6g8)
Loading…
↗
25
92907−04600
Washer(jf2)
Loading…
↗
26
62Y−11356−00
Seal, cylinder 2
Loading…
↗
27
90119−06MA2
Bolt, with washer
Loading…
↗
28
62Y−11119−00
Hanger, engine
Loading…
↗
31
90430−08143
Gasket (256-11198-00)
Loading…
↗
32
97095−08014
Bolt, hexagon deep recess
Loading…
↗
33
6G8−15363−00
Plug, oil
Loading…
↗
34
93210−24M79
O-ring
Loading…
↗
35
62Y−12138−60
Mark, Caution
Loading…
↗
36
94701−00406
Plug, spark (dpr5ea-9)
Loading…
↗
