FT8DMH (2002)
CYLINDER. CRANKCASE 2
Diagram: CYLINDER. CRANKCASE 2
Parts List
Reference
Description
Price
3
67D−11133−10
Guide, valve 1
Loading…
↗
4
68T−11181−00
Gasket, cylinder head 1
Loading…
↗
5
99510−10114
Pin, dowel(3vd)
Loading…
↗
6
90105−08M36
Bolt (6g8)
Loading…
↗
7
90105−08M78
Bolt, washer based
Loading…
↗
8
90119−06049
Bolt, with washer
Loading…
↗
10
650−24378−00
Pipe, joint 2
Loading…
↗
11
68T−11356−00
Seal, cylinder 2
Loading…
↗
12
97095−06020
Bolt(7u8)
Loading…
↗
13
92995−06600
Washer, plain (646)
Loading…
↗
14
68T−11168−00
Cover, breather
Loading…
↗
15
68T−11169−A0
Gasket, breather cover
Loading…
↗
16
98507−04010
Screw, pan head(6g8)
Loading…
↗
17
92907−04600
Washer(jf2)
Loading…
↗
18
68T−11325−00
Anode
Loading…
↗
19
90151−05M05
Screw, countersunk
Loading…
↗
20
6G8−11197−01
Plug, blind
Loading…
↗
21
93210−13M63
O-ring (6g8)
Loading…
↗
22
6G8−15363−00
Plug, oil
Loading…
↗
23
93210−24M79
O-ring
Loading…
↗
24
94702−00274
Plug, spark (br6hs-10)
Loading…
↗
