F4AMH (1998)
Control
Diagram: Control
Parts List
Reference
Description
Price
1
67D441110000
Handle, gear shift
Loading…
↗
2
986800552000
Ybs53-520 screw,flat head
Loading…
↗
3
67DWG411009M
Change shaft set
Loading…
↗
4
932101232700
O-ring(3ld)
Loading…
↗
5
905011227400
Spring 6554411600
Loading…
↗
6
935051602400
Ball
Loading…
↗
7
6E0441210000
Lever, shift rod 1
Loading…
↗
8
9010106M2700
Bolt
Loading…
↗
9
929950660000
Washer, plain (646)
Loading…
↗
10
67D441430000
Rod Shift
Loading…
↗
11
929900660000
Washer, plain (646)
Loading…
↗
12
914901601000
Pin, cotter
Loading…
↗
13
67D441450000
Connector, shift rod 1
Loading…
↗
14
67D441460000
Connector, shift rod 2
Loading…
↗
15
958950602000
Bolt, flange(jk3)
Loading…
↗
