2BMH (1997)
Cylinder & Crankcase
Diagram: Cylinder & Crankcase
Parts List
Reference
Description
Price
1
6A1W00901300
Crank Cylinder Assembly
Loading…
↗
2
6A1151006194
Crankcase Assembly
Loading…
↗
3
903360600100
Plug, blind 6551131300
Loading…
↗
4
650144850200
Pipe, joint
Loading…
↗
5
624113790000
Valve, check
Loading…
↗
6
970950604000
Bolt (682)
Loading…
↗
7
929900660000
Washer, plain (646)
Loading…
↗
8
995301001400
Pin, dowel
Loading…
↗
9
6A111111021S
Head, cylinder 1
Loading…
↗
10
6A111181A100
Gasket, cylinder head 1
Loading…
↗
11
970950602500
Bolt
Loading…
↗
13
6GDE14000000
Crankshaft assembly
Loading…
↗
14
933060040900
Brg,r-b 6004 42mm 69g nk
Loading…
↗
15
933063020400
Brg,r-b 6302 42mm 82g nk
Loading…
↗
16
93310210V100
Bearing (27v)
Loading…
↗
17
931022081400
Oil seal
Loading…
↗
18
902013530000
Washer, Plate
Loading…
↗
19
9310215M3200
Oil seal(6a1)
Loading…
↗
20
646116360100
Piston (0.50Mm O/s)
Loading…
↗
21
646116010100
Piston Ring Set (Std)
Loading…
↗
22
646116330000
Pin,piston
Loading…
↗
23
934501102100
Circlip 101116340000
Loading…
↗
25
904670601600
Clip (655)
Loading…
↗
26
6A1136100000
Reed valve assembly
Loading…
↗
27
6A1W00040000
Reed set
Loading…
↗
28
6A113621A000
Gasket, valve seat
Loading…
↗
29
6A1241410000
Protector, fuel tank
Loading…
↗
30
958800601000
Bolt, flange(7ht)
Loading…
↗
32
904650802800
Clamp (1e6)
Loading…
↗
34
6A1157710000
Stay 1
Loading…
↗
35
970130606000
Bolt, hexagon
Loading…
↗
