20DMHO (2001)
Cylinder. Crankcase
Diagram: Cylinder. Crankcase
Parts List
Reference
Description
Price
1
6L2W0090114D
Crank Cylinder assembly
Loading…
↗
2
6L2151001094
Crankcase assembly
Loading…
↗
3
6E5113720000
Nipple, hose
Loading…
↗
4
9044507M9000
Hose (l390)
Loading…
↗
5
904670601600
Clip (655)
Loading…
↗
6
9360412M0700
Pin, dowel (688)
Loading…
↗
7
956170864500
Bolt, stud(6l2)
Loading…
↗
8
902010808600
Washer (1t1)
Loading…
↗
9
997800860000
Nut, hex.
Loading…
↗
10
9011908M6500
Bolt, with washer
Loading…
↗
11
9011906M1400
Bolt, with washer (677)
Loading…
↗
12
6J8113250000
Anode
Loading…
↗
13
6H3113270094
Cover, anode
Loading…
↗
14
6H3113280000
Grommet, anode
Loading…
↗
15
970140601600
Bolt, hexagon deep recess
Loading…
↗
16
929030660000
Washer, plain (646)
Loading…
↗
17
6L2111110194
Head, cylinder 1
Loading…
↗
18
6L211181A300
Gasket, cylinder head 1
Loading…
↗
19
6L211191009M
Cover, cylinder head 1
Loading…
↗
20
6L211193A100
Gasket, head cover 1
Loading…
↗
21
9011908M9100
Bolt, with washer
Loading…
↗
22
901190602300
Bolt, with washer
Loading…
↗
23
6E5124113000
Thermostat
Loading…
↗
24
6H412413009M
Cover, thermostat
Loading…
↗
25
6J812414A000
Gasket, cover
Loading…
↗
26
9011906MA300
Bolt, with washer
Loading…
↗
27
6L241111001S
Inner cover, exhaust
Loading…
↗
28
6L241112A100
Gasket, exhaust inner cover
Loading…
↗
29
6L241113009M
Outer cover, exhaust
Loading…
↗
30
676113720000
Nipple, hose
Loading…
↗
31
6L241114A100
Gasket, exhaust outer cover
Loading…
↗
32
9011906MA400
Bolt, with washer
Loading…
↗
33
9044510M4000
Hose (l400)
Loading…
↗
34
6L245113A100
Gasket, upper casing
Loading…
↗
35
947020027100
Plug, spark (br7hs-10)
Loading…
↗
