Helm Master EX (2020)
DEC 2 (MULTIPLE)
Diagram: DEC 2 (MULTIPLE)
Parts List
Reference
Description
Price
1
6X948A0200
NOT FOR SALE
Remote control box
Loading…
↗
2
6X94822B00
Grip, lever multi
Loading…
↗
3
6X94812700
Screw 1
Loading…
↗
4
9299005300
Washer, tooth
Loading…
↗
5
6X94822200
Grip, control lever
Loading…
↗
8
6X94840000
Cover assembly
Loading…
↗
9
6X94269700
Tuning fork mark
Loading…
↗
10
6X94811900
Cover
Loading…
↗
11
6X94816700
Plug
Loading…
↗
12
6X94816800
Plug 2
Loading…
↗
13
6X94817600
Grommet
Loading…
↗
14
9778050145
UR
Screw, pan head tapping
Loading…
↗
14
9858005060
UR
Screw, panhead
Loading…
↗
15
7044828700
Washer 1
Loading…
↗
16
9538005600
Nut, hexagon (663)
Loading…
↗
