Yamaha Outboard Parts - DEC 3 (FLUSH SIDE MOUNT) - Helm Master EX (2021) | Flood Marine

Diagram: DEC 3 (FLUSH SIDE MOUNT)

Diagram

Parts List

Reference
Description
Price


1
6X948A0000 NOT FOR SALE
-
Loading…

↗
2
6X94816600
Plug
Loading…

↗
3
6X78257501
Engine stop switch assembly
Loading…

↗
4
6X94823B00
Packing 2
Loading…

↗
5
9878006035 UR
Screw flat head
Loading…

↗
5
9778006230 UR
Screw, tapping
Loading…

↗
6
7014828700
Washer 1
Loading…

↗
7
6X04815600
Nut 1
Loading…

↗
8
6X94282100
Band, clamp
Loading…

↗
9
6X94269700
Tuning fork mark
Loading…

↗
