RIGGING - METER (2018)
DIGITAL NETWORK GAUGE 1
Diagram: DIGITAL NETWORK GAUGE 1
Parts List
Reference
Description
Price
1
6Y88350T20
Tachometer, rd
Loading…
↗
2
6Y88350020
SPEED & FUEL
S & fm meter, rd
Loading…
↗
3
6Y88351400
UN
Plate, fitting
Loading…
↗
4
6Y88368801
Transom Mount Triducer
Loading…
↗
5
6Y88368811
PLASTIC BODY
Plastic Thru-Hull Triducer
Loading…
↗
6
6Y88368820
BRONZE BODY
Bronze Thru-Hull Triducer
Loading…
↗
7
6Y98368800
Sensor assembly
Loading…
↗
8
6Y98A2D040
GATEWAY
Interface Unit
Loading…
↗
9
6Y98A2D030
ANALOGE GAUGE
Analog gauge interface
Loading…
↗
