RIGGING - METER (2021)
DIGITAL NETWORK GAUGE 3
Diagram: DIGITAL NETWORK GAUGE 3
Parts List
Reference
Description
Price
1
60V8A4L01A
Sensor, module
Loading…
↗
2
60V8366D00
Adaptor, input
Loading…
↗
3
95D9506025
Bolt, flange deep recess
Loading…
↗
4
60V8366700
Sender, water pressure
Loading…
↗
5
9043014115
Gasket (663)
Loading…
↗
6
9044507018
Hose (l1457)
Loading…
↗
7
9044707015
Hose, cover (l: 1300mm)
Loading…
↗
8
9046511M10
Clamp
Loading…
↗
9
6AW8366B02
Sensor, water pressure
Loading…
↗
10
60V8257V00
Plate, connector
Loading…
↗
11
97E9506516
Bolt, hexagon w/w deep recess
Loading…
↗
12
9046409021
Clamp
Loading…
↗
13
9010906M81
Bolt
Loading…
↗
