Yamaha Outboard Parts - DIGITAL NETWORK GAUGE 6 - RIGGING - METER (2010) | Flood Marine

Diagram: DIGITAL NETWORK GAUGE 6

Diagram

Parts List

Reference
Description
Price


1
60V8A4L111
Sensor, module 1
Loading…

↗
2
6AW8366B00
Sensor, water pressure
Loading…

↗
3
60V8366D00
Adaptor, input
Loading…

↗
4
9010906M81
Bolt
Loading…

↗
5
9046511M10
Clamp
Loading…

↗
6
9044507017
Hose (l550)
Loading…

↗
7
9044707013
Hose, cover (l: 700mm)
Loading…

↗
8
60V4262900
Seal
Loading…

↗
9
9709506016
Bolt, hexagon deep recess
Loading…

↗
10
9299506600
Washer, plain (646)
Loading…

↗
