Yamaha Outboard Parts - DIGITAL NETWORK GAUGE 7 - RIGGING - METER (2011) | Flood Marine

Diagram: DIGITAL NETWORK GAUGE 7

Diagram

Parts List

Reference
Description
Price


1
6AW8A4L101
Sensor, module 1
Loading…

↗
2
9046506M86
Clamp
Loading…

↗
3
9046514M66
Clamp
Loading…

↗
4
9044707015
Hose, cover (l: 1300mm)
Loading…

↗
5
9044507018
Hose (l1457)
Loading…

↗
6
9709506016
Bolt, hexagon deep recess
Loading…

↗
7
9299506600
Washer, plain (646)
Loading…

↗
8
60V8366D00
Adaptor, input
Loading…

↗
9
6AW8366B00
Sensor, water pressure
Loading…

↗
