RIGGING - METER (2017)
DIGITAL NETWORK GAUGE 7
Diagram: DIGITAL NETWORK GAUGE 7
Parts List
Reference
Description
Price
1
60V8A4L203
Sensor, Module 2
Loading…
↗
2
6AW8366B01
Sensor, water pressure
Loading…
↗
3
60V8366D00
Adaptor, input
Loading…
↗
4
9589506025
Bolt, flange deep recess
Loading…
↗
5
60V8366700
Sender, water pressure
Loading…
↗
6
9043014115
Gasket (663)
Loading…
↗
7
9044507018
Hose (l1457)
Loading…
↗
8
9044707015
Hose, cover (l: 1300mm)
Loading…
↗
9
9046511M10
Clamp
Loading…
↗
10
60V8257V00
Plate, connector
Loading…
↗
11
9759506516
Bolt, with washer(6r6)
Loading…
↗
12
9046409021
Clamp
Loading…
↗
13
9010906M81
Bolt
Loading…
↗
17
9044507017
Hose (l550)
Loading…
↗
18
9044707013
Hose, cover (l: 700mm)
Loading…
↗
19
60V4262900
Seal
Loading…
↗
