75AED (2007)
ELECTRICAL
Diagram: ELECTRICAL
Parts List
Reference
Description
Price
1
6888554000
C.d.i. unit assembly
Loading…
↗
2
9788006040
Screw pan head
Loading…
↗
3
9299006100
Washer(6a1)
Loading…
↗
4
9299006600
Washer, plain (646)
Loading…
↗
5
6978557000
Ignition coil assembly
Loading…
↗
6
9709506020
Bolt(7u8)
Loading…
↗
7
9299506600
Washer, plain (646)
Loading…
↗
8
6H08196000
Rectifier & regulator assembly
Loading…
↗
9
9709506012
Bolt(gh1)
Loading…
↗
10
9299506100
Washer(6a1)
Loading…
↗
13
6G18194110
Starter relay
Loading…
↗
14
6G18195200
Holder, relay
Loading…
↗
15
6E98194570
Plate, switch fitting
Loading…
↗
16
9701306016
Bolt, hexagon deep recess
Loading…
↗
17
9290306600
Washer, plain (646)
Loading…
↗
18
6G58215200
Holder, fuse
Loading…
↗
19
6H1855420094
Bracket
Loading…
↗
20
9048009M25
Grommet(688)
Loading…
↗
21
9038706M03
Collar (676)
Loading…
↗
22
9011906M75
Bolt, with washer
Loading…
↗
23
9010906M39
Bolt(6h0)
Loading…
↗
24
9020106M31
Washer (6a0)
Loading…
↗
25
6H18191600
Cover, terminal
Loading…
↗
26
9015906M11
Screw, with washer(6l2)
Loading…
↗
27
6G18237021
Plug cap assembly
Loading…
↗
28
6888256010
Thermo switch assembly
Loading…
↗
29
6888258801
Plate
Loading…
↗
30
6888259017
Wire harness assembly
Loading…
↗
31
6638215100
Fuse
Loading…
↗
32
6H08210502
Battery cable
Loading…
↗
33
6H08211700
Wire, lead
Loading…
↗
34
6978251900
Wire,earth lead
Loading…
↗
35
6888259400
Clamp
Loading…
↗
36
7038211900
Cover, lead wire
Loading…
↗
37
6N68258200
Cover, wire harness
Loading…
↗
38
9046511M10
Clamp
Loading…
↗
