40XWT (2002)
ELECTRICAL 1
Diagram: ELECTRICAL 1
Parts List
Reference
Description
Price
1
66T--8554B--01--94
Bracket
Loading…
↗
2
6A0--82317--00
Damper, ignition coil
Loading…
↗
3
624--42542--00
Collar
Loading…
↗
4
90119--06M65
Bolt, with washer
Loading…
↗
5
66T8554000
C.d.i. unit assembly
Loading…
↗
6
90109--06M81
Bolt
Loading…
↗
7
90109--06M80
Bolt
Loading…
↗
8
66T--81916--01
Cover, terminal
Loading…
↗
10
66T--85570--00
Ignition coil assembly
Loading…
↗
11
90480--25161
Grommet(656)
Loading…
↗
12
90446--03MA3
Hose
Loading…
↗
14
97095--06025
Bolt
Loading…
↗
15
92995--06600
Washer, plain (646)
Loading…
↗
16
6E3--82370--21
Plug cap assembly
Loading…
↗
17
97095--06012
Bolt(gh1)
Loading…
↗
19
688--82560--10
Thermo switch assembly
Loading…
↗
20
66T--82519--00
Wire, earth lead
Loading…
↗
21
6G1--42725--00
Grommet
Loading…
↗
