20DMHO (2002)
ELECTRICAL 2
Diagram: ELECTRICAL 2
Parts List
Reference
Description
Price
1
6G1−81941−10
Starter relay
Loading…
↗
2
6G1−81952−00
Holder, relay
Loading…
↗
3
6L2−81945−00
Plate, switch fitting
Loading…
↗
4
97095−06012
Bolt(gh1)
Loading…
↗
5
92995−06100
Washer(6a1)
Loading…
↗
6
6G1−82105−01
Battery cable
Loading…
↗
7
6G1−82117−00
Wire, lead
Loading…
↗
8
6G1−81970−61
Rectifier assembly
Loading…
↗
9
6G1−82151−00
Fuse (10a)
Loading…
↗
10
97880−05025
Screw, panhead (a93)
Loading…
↗
11
92990−05600
Washer, plain (646)
Loading…
↗
12
6G5−82152−00
Holder, fuse
Loading…
↗
13
6L2−86111−00
Coil, solenoid
Loading…
↗
14
682−86117−00
Hook, wire pull
Loading…
↗
15
6L2−86115−00
Holder, solenoid
Loading…
↗
16
97880−05008
Screw, with washer
Loading…
↗
18
90480−10155
Grommet(664)
Loading…
↗
19
97880−04008
Screw, pan head (713)
Loading…
↗
20
92990−04600
Washer, plain (646)
Loading…
↗
21
6L2−86112−00
Stay, solenoid
Loading…
↗
24
93210−03261
O-ring (663)
Loading…
↗
27
6L2−82590−00
Wire harness assembly
Loading…
↗
28
6K3−83557−00
Tube
Loading…
↗
