F250AET (2012)
ELECTRICAL 2
Diagram: ELECTRICAL 2
Parts List
Reference
Description
Price
1
6P28196002
Rectifier & regulator assembly
Loading…
↗
2
6P28161400
Protector
Loading…
↗
3
60V81975A0
Plate, rectifier fitting
Loading…
↗
4
6P281972009S
Cover, rectifier
Loading…
↗
5
9011906MA3
Bolt, with washer
Loading…
↗
6
9011906MA5
Bolt, with washer
Loading…
↗
7
6P21249100
Clamp 1
Loading…
↗
8
9709506012
Bolt(gh1)
Loading…
↗
9
9299506600
Washer, plain (646)
Loading…
↗
10
6E51132500
Anode
Loading…
↗
11
9878004015
Screw, flat head(ga5)
Loading…
↗
12
9046418004
Clamp
Loading…
↗
13
6P28192501
Terminal
Loading…
↗
14
9709508020
Bolt, hexagon
Loading…
↗
15
9299508600
Washer, plain (663)
Loading…
↗
16
9046513M18
Clamp
Loading…
↗
59
9709508016
AP
Bolt, hexagon deep recess
Loading…
↗
19
6P28194800
Bracket
Loading…
↗
21
9046514M66
Clamp
Loading…
↗
22
6A08231700
Damper, ignition coil
Loading…
↗
23
9038706119
Collar
Loading…
↗
24
9011906M95
Bolt, with washer
Loading…
↗
25
63P8195000
Relay assembly
Loading…
↗
26
9759506610
Bolt, hexagon w/w deep recess
Loading…
↗
27
9701306025
Bolt(62y)
Loading…
↗
28
9290306600
Washer, plain (646)
Loading…
↗
29
6P28183X00
Cap, terminal
Loading…
↗
30
9709506016
Bolt, hexagon deep recess
Loading…
↗
31
9299506100
Washer(6a1)
Loading…
↗
33
6P28211900
Cover, lead wire
Loading…
↗
34
6P28217010
Fuse box assembly
Loading…
↗
35
6P28215100
Fuse (60a)
Loading…
↗
36
67F8215100
Fuse
Loading…
↗
37
67F8215110
Fuse
Loading…
↗
38
67F8215140
Fuse (10a)
Loading…
↗
39
67F8215150
Fuse (15a)
Loading…
↗
40
67F2812A00
Puller, fuse
Loading…
↗
41
68F8284600
Screw, pan head (m5)
Loading…
↗
42
6P28211300
Screw (m3)
Loading…
↗
43
6P28163900
Cover
Loading…
↗
44
6P28554400
Case
Loading…
↗
45
68F8195A00
Relay assembly
Loading…
↗
46
9778050620
Screw, tapping
Loading…
↗
47
6P28133600
Grommet
Loading…
↗
48
9046208026
Clamp
Loading…
↗
54
6P28259M00
Wire harness assembly 2
Loading…
↗
55
9046409M47
Clamp(65j)
Loading…
↗
56
6P28191940
Graphic, regulator
Loading…
↗
57
6P28191931
Graphic, regulator
Loading…
↗
58
6P28192300
AP
Washer
Loading…
↗
60
9533308600
AP
Nut(6l2)
Loading…
↗
61
9290308100
AP
Ybs67-8 washer, spring
Loading…
↗
62
6P28210501
AP
Wire harness
Loading…
↗
