FT25BED (2002)
ELECTRICAL 2
Diagram: ELECTRICAL 2
Parts List
Reference
Description
Price
1
65W--85790--00
Thermosensor assembly
Loading…
↗
2
65W--85757--00
Retainer
Loading…
↗
3
97095--06012
Bolt(gh1)
Loading…
↗
4
92995--06600
Washer, plain (646)
Loading…
↗
5
90465--11M10
Clamp
Loading…
↗
6
65W--82105--00
Battery cable
Loading…
↗
7
65W--82590--10
Wire Harness assembly (7P)
Loading…
↗
7
65W--82590--30
Wire Harness assembly
Loading…
↗
8
90465--08M08
Clamp (6e5)
Loading…
↗
9
90465--06M88
Clamp
Loading…
↗
10
6N7--83557--00
I.DIA.) 22MM
Tube
Loading…
↗
11
97095--06016
Bolt, hexagon deep recess
Loading…
↗
13
97095--05016
Bolt(6a1)
Loading…
↗
14
92995--05600
Washer, plain (646)
Loading…
↗
15
6G8--82150--00
Fuse holder assembly
Loading…
↗
16
663--82151--00
Fuse
Loading…
↗
17
6G5--82152--00
Holder, fuse
Loading…
↗
21
61A--81950--00
Relay assembly
Loading…
↗
22
97075--06020
Bolt(7u8)
Loading…
↗
24
65W8194800
Bracket
Loading…
↗
25
6A0--82317--00
Damper, ignition coil
Loading…
↗
26
624--42542--00
Collar
Loading…
↗
27
95895--06030
Bolt, flange deep recess
Loading…
↗
28
90201--12M16
Washer, plate (679)
Loading…
↗
29
65W--81949--00
Wire, Lead
Loading…
↗
30
682--82119--01
Cover, lead wire
Loading…
↗
31
97575--06516
Bolt, hexagon w/w deep recess
Loading…
↗
33
6H1--82563--10
Trim & tilt switch assembly
Loading…
↗
34
6E5--82587--00
Gasket
Loading…
↗
35
62Y8361400
Bracket
Loading…
↗
36
90109--06M86
Bolt
Loading…
↗
