FT9.9DE (2008)
ELECTRICAL 2
Diagram: ELECTRICAL 2
Parts List
Reference
Description
Price
1
6G18194110
Starter relay
Loading…
↗
2
6G18195200
Holder, relay
Loading…
↗
3
66M8211700
Wire, lead
Loading…
↗
4
65W8182B00
Nut, special
Loading…
↗
5
66R8210500
Battery cable
Loading…
↗
6
9538008700
Nut(661)
Loading…
↗
7
9299008600
Washer, plain (663)
Loading…
↗
8
66M8611100
Coil, solenoid
Loading…
↗
9
66M8611600
Wire, Pull
Loading…
↗
10
66M8611200
Stay, Solenoid
Loading…
↗
11
9788005008
Screw, with washer
Loading…
↗
12
9299005600
Washer, plain (646)
Loading…
↗
13
9709506016
Bolt, hexagon deep recess
Loading…
↗
14
9299506600
Washer, plain (646)
Loading…
↗
15
9048010M13
Grommet (6e0)
Loading…
↗
16
66M8611700
Hook, wire pull
Loading…
↗
17
9321003261
O-ring (663)
Loading…
↗
18
66M8259000
Wire Harness assembly
Loading…
↗
19
6G14272500
Grommet
Loading…
↗
