F40FED (2010)
ELECTRICAL 4
Diagram: ELECTRICAL 4
Parts List
Reference
Description
Price
1
9709506016
Bolt, hexagon deep recess
Loading…
↗
2
9299506600
Washer, plain (646)
Loading…
↗
3
9046413249
Clamp
Loading…
↗
5
6C58579000
Thermosensor assembly
Loading…
↗
6
9043014115
Gasket (663)
Loading…
↗
7
6BG8238800
Plate
Loading…
↗
10
9046406001
Clamp
Loading…
↗
11
64J8250400
Oil pressure switch assembly
Loading…
↗
12
68V8131500
Lead wire assembly
Loading…
↗
13
6BG8257V00
Plate, connector
Loading…
↗
16
9046418246
Clamp(4tr)
Loading…
↗
17
9010906MA1
Bolt
Loading…
↗
18
6BG8194200
Cover
Loading…
↗
19
9046513M24
Band, switch cord
Loading…
↗
20
9048012314
Grommet(3aa)
Loading…
↗
21
6BG1119200
Cover, cylinder head 2
Loading…
↗
