Yamaha Outboard Parts - ELECTRICAL 4 - LZ250DETO (2003) | Flood Marine

Diagram: ELECTRICAL 4

Diagram

Parts List

Reference
Description
Price


1
60V−82588−00
Plate
Loading…

↗
2
97095−06012
Bolt(gh1)
Loading…

↗
3
92995−06600
Washer, plain (646)
Loading…

↗
4
61A−85790−00
Thermosensor assembly
Loading…

↗
5
92990−10600
Washer, plate
Loading…

↗
6
61A−85895−00
Crank position sender
Loading…

↗
7
97885−05012
Screw,pan head (646)
Loading…

↗
8
688−82560−10
Thermo switch assembly
Loading…

↗
9
90446−10M87
Hose
Loading…

↗
