F225FET (2011)
ELECTRICAL 5
Diagram: ELECTRICAL 5
Parts List
Reference
Description
Price
1
9701308045
Bolt
Loading…
↗
2
9290308600
Washer, plain (663)
Loading…
↗
3
9017908003
Nut
Loading…
↗
4
9015904005
Screw, with washer
Loading…
↗
5
6CB8182200
Bracket, starting motor
Loading…
↗
6
9010508M87
Bolt, washer based
Loading…
↗
7
6CB8144300
Clamp, lead 1
Loading…
↗
8
9589506016
Bolt, flange deep recess
Loading…
↗
9
6CB8182300
Stay, starting motor
Loading…
↗
10
9360612019
Pin, dowel (614)
Loading…
↗
11
9010506151
Bolt, flange
Loading…
↗
12
9046413227
Clamp
Loading…
↗
13
9046418004
Clamp
Loading…
↗
14
6CE8259M00
Wire harness assembly 2
Loading…
↗
15
6CE8194900
AP
Wire, lead (isolator cable)
Loading…
↗
