Yamaha Outboard Parts - ELECTRICAL 5 - XF375NSA (2018) | Flood Marine

Diagram: ELECTRICAL 5

Diagram

Parts List

Reference
Description
Price


1
6GR8259000
Wire harness assembly
Loading…

↗
2
9046409M47
Clamp(65j)
Loading…

↗
3
6GR8211900
Cover, lead wire
Loading…

↗
4
9046412012
Clamp
Loading…

↗
5
9046409013
Clamp
Loading…

↗
6
9046412010
Clamp
Loading…

↗
7
9046513M24
Band, switch cord
Loading…

↗
8
9046418004
Clamp
Loading…

↗
9
9046511M59
Clamp(63m)
Loading…

↗
10
9759506516
Bolt, with washer(6r6)
Loading…

↗
11
6GR8259M00
Wire harness assembly 2
Loading…

↗
13
6GR8211910
Cover, lead wire
Loading…

↗
14
9046444002
Clamp
Loading…

↗
