F200SA2 (2023)
ELECTRICAL 6
Diagram: ELECTRICAL 6
Parts List
Reference
Description
Price
1
6LH8650000
Motor control unit assembly
Loading…
↗
2
6LH8259N00
Wire harness assembly 3
Loading…
↗
3
6LH8259N10
Wire harness assembly 3
Loading…
↗
4
6LH8259N20
Wire harness assembly 3
Loading…
↗
5
6LH8259N30
Wire harness assembly 3
Loading…
↗
6
6LH8611500
Holder, solenoid
Loading…
↗
7
6LH8192000
Terminal assembly
Loading…
↗
8
6GR8215110
Fuse (70a)
Loading…
↗
9
95D9506016
Bolt, flange deep recess
Loading…
↗
10
6LH8192500
Terminal
Loading…
↗
11
9578006500
Nut, flange(7nb)
Loading…
↗
12
9538005600
Nut, hexagon (663)
Loading…
↗
13
9290305100
Ybs67-5 washer, spring
Loading…
↗
14
9581406016
Bolt, flange
Loading…
↗
15
97E9506510
Bolt, hexagon w/w deep recess
Loading…
↗
16
6GR8211900
Cover, lead wire
Loading…
↗
17
6LH8363500
Bracket
Loading…
↗
18
6LH8612800
Cover
Loading…
↗
19
9138005016
Bolt
Loading…
↗
20
9759505510
Bolt hex. head
Loading…
↗
22
95D9506040
Bolt, flange deep recess
Loading…
↗
23
6LH8184200
Cover
Loading…
↗
25
6LH818D200
Plate, 2
Loading…
↗
26
97E9506516
Bolt, hexagon w/w deep recess
Loading…
↗
