XF450NSA (2025)
EXHAUST 2
Diagram: EXHAUST 2
Parts List
Reference
Description
Price
1
6KN14635109S
Joint, Exhaust 3
Loading…
↗
2
6KN14645109S
Joint, Exhaust 4
Loading…
↗
3
6G811197B0
Plug, blind
Loading…
↗
4
9321013M63
O-ring (6g8)
Loading…
↗
5
6G81132500
Anode
Loading…
↗
6
9898005025
Screw, panhead (a93)
Loading…
↗
7
9321065001
O-ring
Loading…
↗
8
9321085003
O-ring
Loading…
↗
9
6KN14656009S
Joint, exhaust 5
Loading…
↗
10
9034018M09
Plug, straight screw
Loading…
↗
11
90201186F1
Washer, plate (22f)
Loading…
↗
12
9010508277
Bolt, flange
Loading…
↗
13
6GR4113400
Gasket, exhaust manifold
Loading…
↗
14
9010508220
Bolt, flange
Loading…
↗
15
9360612019
Pin, dowel (614)
Loading…
↗
16
9044509104
Hose (l1500)
Loading…
↗
17
9044509063
Hose (l1500)
Loading…
↗
18
6882437800
Pipe, joint
Loading…
↗
19
6KN1248100
Pipe 1
Loading…
↗
20
9044509095
-
Loading…
↗
21
9046511M10
Clamp
Loading…
↗
23
9046409028
Clamp
Loading…
↗
24
6KN8258800
Plate
Loading…
↗
25
95D9506016
Bolt, flange deep recess
Loading…
↗
26
9046420181
Clamp(4ap)
Loading…
↗
28
6GR8366B00
Sensor, water pressure
Loading…
↗
29
9046418004
Clamp
Loading…
↗
