6CMH (2003)
FUEL
Diagram: FUEL
Parts List
Reference
Description
Price
1
6G1−24304−02
Fuel pipe joint comp. 1
Loading…
↗
2
97095−06025
Bolt
Loading…
↗
3
92995−06600
Washer, plain (646)
Loading…
↗
4
646−24251−02
Strainer 1
Loading…
↗
5
90445−09221
Hose (l1500)
Loading…
↗
6
90445−09220
Hose (l1500)
Loading…
↗
7
90467−08004
Clip, pipe 6162435600
Loading…
↗
8
6N0−F8100−00
Tool kit
Loading…
↗
9
6N0−F8170−00
6−
Loading…
↗
10
6G1−2811G−00
Band
Loading…
↗
11
97095−06012
Bolt(gh1)
Loading…
↗
13
6L8−F8193−00
AP
Plug, water check
Loading…
↗
14
6M8−F8199−75−A0
UR (E,F,S)
O/m 6c/6d/8c '03 e, f, s
Loading…
↗
14
6M8−F8199−75−B0
UR (D,NL,I)
O/m 6c/6d/8c '03 g, d, i
Loading…
↗
15
6M8−F8199−86−A0
UR (DK,P,GR)
O/m 6cmh/6dmh/8cmh(6m82/92 '03
Loading…
↗
15
6M8−F8199−86−B0
UR (N,S,SS)
O/m 6cmh/6dmh/8cmh(6m82/92 '03
Loading…
↗
