75CETO (2004)
FUEL
Diagram: FUEL
Parts List
Reference
Description
Price
1
6G12430402
Fuel pipe joint comp. 1
Loading…
↗
2
9709506020
Bolt(7u8)
Loading…
↗
3
9299506600
Washer, plain (646)
Loading…
↗
4
9044509104
Hose (l1500)
Loading…
↗
5
9046708004
Clip, pipe 6162435600
Loading…
↗
6
61N2456000
Filter assembly
Loading…
↗
7
61N2456300
Element, filter
Loading…
↗
8
61N2452100
Cup, filter
Loading…
↗
9
9321032738
O-ring(1wg)
Loading…
↗
10
6H12456601
Bracket, filter
Loading…
↗
11
9538008600
Nut (661)
Loading…
↗
12
6922441000
Fuel pump assembly
Loading…
↗
13
6A02441300
Cover, pump
Loading…
↗
14
6922441100
Diaphragm
Loading…
↗
15
6482443401
Gasket, body
Loading…
↗
16
9538003600
Nut (6g8)
Loading…
↗
17
6632441100
Diaphragm
Loading…
↗
18
6482443502
Gasket, body 2
Loading…
↗
19
9850305028
Ybs86-530 screw,panhead
Loading…
↗
20
9299005100
Ybs67-5 washer, spring
Loading…
↗
21
6A02442101
Valve, check
Loading…
↗
22
6A01432500
Screw, pan head
Loading…
↗
23
6A02441202
Body 1
Loading…
↗
24
65024431A0
Gasket,fuel pump
Loading…
↗
25
9709506040
Bolt (682)
Loading…
↗
27
6H12431400
Pipe 4
Loading…
↗
29
9044509097
Hose (l1500)
Loading…
↗
30
6882431300
Pipe, fuel 2
Loading…
↗
31
6882431400
Pipe, fuel 2
Loading…
↗
33
9044509220
Hose (l1500)
Loading…
↗
34
6882437800
Pipe, joint
Loading…
↗
35
61H2819R31
-
Loading…
↗
36
656W281002
Tool kit
Loading…
↗
37
6E0281930094
AP D)12.5MM
Plug, water check
Loading…
↗
38
6H2281997RA0
UR (E,F,S)
Om 50g/75c/90a/60f/70b '04
Loading…
↗
38
6H2281997RB0
UR (D,NL,I)
Om 50g/75c/90a/60f/70b '04
Loading…
↗
39
6H2281998RA0
UR (DK,P,GR)
Om 50geto '04
Loading…
↗
39
6H2281998RB0
UR (N,S,SS)
Om 50geto '04
